BlueWave MX-150 LED Spot-Curing System

BlueWave MX-150 LED Spot-Curing System

High-Intensity Curing System with the Flexibility of Multiple Systems
CE Marked – Available Globally

The BlueWave MX-150™ curing system provides manufacturers with the curing flexibility they need, in a smaller, more efficient design. The unit is comprised of two main parts, a controller with an easy-to-use touchscreen interface and a high-intensity LED emitter which is uniquely designed to offer higher, more consistent curing intensity than traditional spot-curing systems. Curing energy is created using an LED chip in the emitter, unlike traditional spot-cure systems, where it is located in the controller. Locating the LED chip at the point-of-cure provides more consistent curing by addressing potential intensity loss caused by the use of long or bent lightguides.

With this new design, the system can be truly tailored to users’ curing needs – allowing them to choose from three different wavelength LED emitters (365, 385, or 405 nm) so optimal cures are achieved. Users also have endless set up flexibility; for automated curing processes, the emitter can be easily mounted to robotic arms or further from the controller without fear of intensity variations. When used as a bench-top curing system, the unit can be paired with a stand and shielding or a lightguide can be connected to the system for specialized applications.

Heat Control

For applications with heat-sensitive components, interruptions in the exposure duration can slow the materials’ temperature climb during the cure process. This isn’t a concern with the BlueWave MX-150™ because the curing profile can be optimized to reduce the risk of substrate damage.

Admin and Production Modes

The admin mode fully unlocks the device and allows for setting curing time and intensity cycles. Each individual curing cycle can be entered and saved as a program and recalled when needed. The production mode is designed for simple operation by manufacturing personnel. Settings and access to admin mode can be password protected using the full QWERTY keyboard.

Systems and Accessories

A complete BlueWave MX-150™ system features a controller/power supply and LED emitter. Emitters are available in 365, 385, and 405 nm wavelengths. Lightguides and other accessories noted below can be added for specific applications. Components are sold separately.

Units are warrantied against defects in material and workmanship for one year from date of purchase.

PART NUMBERS
System Components
BlueWave MX-150 Controller/Power Supply 42378 North American Power Cord
42379 Asian Power Cord (Type G)
42380 No Power Cord
LED Emitters** 42337 PrimeCure™ (385 nm)
42336 RediCure™ (365 nm)
42338 VisiCure (405 nm)
Lightguides and Optics
Lightguides* 39043 Single-Pole Lightguide, 3-mm x 500 mm
38707 Single-Pole Lightguide, 3-mm x 1,500 mm
38708 Single-Pole Lightguide, 3-mm x 2,000 mm
37043 2-Pole Liquid-Filled Lightguide, 3-mm x 1,000 mm
35101 Single-Pole Lightguide, 5-mm x 500 mm
35102 Single-Pole Lightguide, 5-mm x 1,000 mm
36238 Single-Pole Lightguide, 5-mm x 1,500 mm
38998 Single-Pole Lightguide, 5-mm x 2,000 mm
Lightguide Simulators** 36987 Lightguide Simulator, 5-mm Diameter
Optics 41148 Adjustable Taper Shoulder Focusing Lens (5 mm)
Accessories
Stands & Shielding 42390 Emitter Mounting Stand 41395 Three-Sided Acrylic Shield 42426 Emitter Holder Assembly Bracket
Radiometers 40505 ACCU-CAL™ 50-LED Radiometer Kit for LED Spots, Floods, and BlueWave QX4™

* All standard Wolf entrance fitting lightguides will physically couple to this system,
but only configurations listed above have been tested and verified to be fully functional.

** 5-mm lightguide simulator comes with every emitter.
